Voltmeters are instruments used to measure the electrical potential difference between two points in a circuit. They are used in laboratories, electrical panels, industrial machinery, automotive systems, power supplies, control cabinets, maintenance work and electronic test environments.
Although voltage measurement is also available in most multimeters, dedicated voltmeters remain important where a permanent display, specialized voltage range, high input impedance, panel mounting or application-specific measurement performance is required.
This guide explains how voltmeters work, compares digital, analog and electrostatic voltmeters, explains why voltmeters are connected in parallel and why they have high resistance, and covers the main factors to consider when choosing a voltmeter for industrial and electrical applications.
What Is a Voltmeter?
A voltmeter is an electrical measuring instrument designed to measure voltage between two points.
Voltage represents electrical potential difference. A voltmeter therefore does not normally measure the amount of current flowing through a circuit. Instead, its two measurement terminals are connected across the points whose potential difference is to be determined.
Voltmeters can be portable test instruments, bench instruments or permanently installed panel meters. They may be designed for direct current (DC), alternating current (AC), or both.
What Do Voltmeters Measure?
Voltmeters measure electrical potential difference, usually expressed in volts (V), millivolts (mV) or kilovolts (kV), depending on the application.
A voltmeter can be used to check:
- power-supply output voltage
- battery voltage
- voltage across an electrical component
- control-circuit voltage
- panel or machine supply voltage
- voltage drop across a connection or conductor
- AC mains or distribution voltage when the instrument is appropriately rated
How Do Voltmeters Work?
A voltmeter measures the potential difference between its two input terminals while drawing as little current as practical from the circuit being measured.
In an analog voltmeter, the input voltage is converted into a current or force that moves a pointer across a calibrated scale. In a digital voltmeter, the input signal is conditioned and converted into a digital value by electronic measurement circuitry before being shown on a display.
The measurement circuit is designed so that connecting the voltmeter has minimal effect on the voltage being measured. This is why voltmeter input resistance or input impedance is an important specification.
Why Are Voltmeters Connected in Parallel?
A voltmeter is connected in parallel with the component, source or section of circuit whose voltage is being measured because voltage is the potential difference between two points.
Connecting the meter across those two points allows it to compare their electrical potentials directly.
A voltmeter should not normally be inserted in series like an ammeter. Because a voltmeter has high input resistance, placing it in series can significantly disturb or interrupt the circuit and produce an invalid measurement.
Why Do Voltmeters Have High Resistance?
An ideal voltmeter would draw no current from the circuit being measured. Real instruments cannot achieve infinite resistance, but they are designed with high input resistance or impedance to minimize loading.
If a voltmeter drew substantial current, it could change the voltage distribution in the circuit and cause the measured value to differ from the voltage that existed before the meter was connected.
High input impedance is particularly important in high-resistance electronic circuits, sensors and low-power systems where even a small measurement current can influence the result.
Main Types of Voltmeters
A common broad classification divides voltmeters into analog and digital instruments, but voltmeters can also be classified by sensing principle, installation style and application.
Digital Voltmeters
Digital voltmeters display the measured voltage as a numerical value. The input voltage is conditioned by the instrument and converted into a digital representation using electronic measurement circuitry.
Digital voltmeters are common in laboratories, industrial panels, power supplies, production equipment and electronic test systems because they can provide clear readings, high input impedance and convenient integration with digital electronics.
Depending on the instrument, additional features can include autoranging, min/max capture, data logging, remote communication and alarm outputs.
Analog Voltmeters
Analog voltmeters use a pointer moving across a calibrated scale.
They can be useful where an operator wants to see the direction and rate of change of a voltage at a glance. They are still found in some electrical panels, legacy equipment, educational systems and applications where a continuously moving indication is preferred.
Analog instruments can be affected by scale-reading error and generally provide lower input resistance than many modern digital instruments, depending on their design and range.
Electrostatic Voltmeters
Electrostatic voltmeters use electrostatic force as part of the measurement principle rather than relying on a conventional current-driven meter movement.
They are particularly relevant to high-voltage and specialized electrostatic measurements because they can present extremely high input resistance and draw very little current from the measured source.
Electrostatic voltmeters may be used in laboratories, high-voltage testing, electrostatic processes and specialized electrical research.
Panel Voltmeters
Panel voltmeters are designed for permanent installation in electrical panels, control cabinets, machines, generators, power supplies and battery systems.
They provide operators with a continuous local indication of voltage. Digital and analog panel voltmeters are both available, and some digital models include programmable alarms or communication outputs.
Portable Voltmeters
Portable voltmeters are used for field measurements, troubleshooting and maintenance. Many modern portable voltage measurements are performed with digital multimeters, but dedicated portable voltmeters are still used where application-specific performance or simplified operation is preferred.
Digital vs Analog Voltmeters
| Characteristic | Digital Voltmeter | Analog Voltmeter |
|---|---|---|
| Display | Numerical | Pointer and scale |
| Reading | Direct value | Read from scale position |
| Input impedance | Typically high | Depends strongly on movement and range |
| Trend visibility | May use bar graph or logging | Pointer movement naturally shows changes |
| Integration | Well suited to digital systems and communications | Usually simple local indication |
| Typical use | Modern industrial, laboratory and electronic measurement | Legacy equipment, panels and visual trend indication |
AC vs DC Voltmeters
DC voltmeters measure direct voltage, where polarity remains fixed under normal conditions. AC voltmeters measure alternating voltage, where polarity and magnitude vary with time.
Some voltmeters are dedicated to one type, while many digital instruments support both AC and DC measurement.
When measuring AC, the instrument's specified frequency range and measurement method are important. A meter that is suitable for mains-frequency sine waves may not necessarily provide accurate results on higher-frequency or strongly distorted waveforms.
True-RMS Voltage Measurement
For AC measurements, some digital voltmeters and multimeters provide true-RMS capability.
True-RMS measurement is useful when the waveform is not a clean sine wave, such as in circuits involving variable-frequency drives, switching power supplies or electronic controls.
True-RMS capability does not remove all measurement limits. The waveform must remain within the instrument's specified voltage range, bandwidth and other operating limits.
Voltmeter vs Ammeter
Voltmeters and ammeters measure different electrical quantities and are connected differently.
| Characteristic | Voltmeter | Ammeter |
|---|---|---|
| Measures | Voltage / potential difference | Current |
| Typical connection | Parallel with the measured points | Series with the current path |
| Desired internal resistance | High | Low |
| Main objective | Minimize current drawn from measured circuit | Minimize voltage drop introduced into current path |
This difference explains why a voltmeter should not normally be connected like an ammeter, and why an ammeter should not be connected directly across a voltage source.
Voltmeter vs Multimeter
A voltmeter is dedicated primarily to voltage measurement. A multimeter combines several measurement functions in one instrument, usually including voltage, current and resistance.
| Characteristic | Voltmeter | Multimeter |
|---|---|---|
| Primary purpose | Voltage measurement | Multiple electrical measurements |
| Voltage measurement | Yes | Yes |
| Current measurement | Normally no | Common |
| Resistance measurement | Normally no | Common |
| Permanent panel use | Very common | Less common |
| Field troubleshooting | Useful for voltage-specific work | More versatile |
For broader electrical troubleshooting, see FactoryMore's guide to multimeters.
How Is a Voltmeter Used in a Circuit?
The exact procedure depends on the instrument and circuit, but the general measurement concept is:
- determine whether the voltage is AC or DC
- confirm that the expected voltage is within the meter's rating
- select the appropriate function and range if required
- connect the two voltage inputs across the points to be measured
- observe polarity for DC measurements
- read the displayed or indicated voltage
Measurements on energized electrical systems can involve shock, arc and equipment-damage hazards. Only use instruments, probes and procedures appropriate to the electrical environment, and follow applicable safety rules and the instrument manufacturer's instructions.
How Do You Read a Voltmeter?
A digital voltmeter normally displays the voltage directly in volts or another selected unit.
For an analog voltmeter, the operator must identify the active measurement range and read the pointer position on the corresponding scale. If the scale and selected range differ, the indicated value may need to be converted according to the instrument's range relationship.
For DC measurements, a negative digital reading usually indicates that the measurement leads are reversed relative to the expected polarity.
Input Resistance and Input Impedance
Input resistance describes how strongly a DC voltmeter resists current flowing into its input. For AC and frequency-dependent measurements, the broader term input impedance is often more appropriate because capacitance and other circuit effects can also matter.
Higher input impedance generally reduces circuit loading. This is particularly important when measuring sensors, high-resistance networks, low-power electronics and precision circuits.
However, very high input impedance can also allow some meters to display capacitively coupled or so-called ghost voltages in certain electrical installations. Specialized low-impedance measurement modes are sometimes used when this is a concern.
Voltmeter Accuracy and Resolution
Accuracy and resolution are different specifications.
- Accuracy describes how closely the indicated voltage is expected to agree with the actual voltage under specified conditions.
- Resolution describes the smallest change that the instrument can display or resolve.
A digital meter can show many digits without those digits all representing equivalent measurement accuracy. When comparing voltmeters, review the accuracy specification for the actual range, voltage type and frequency of interest.
Display Counts and Digits
Digital voltmeters may be specified by display counts or digits. These specifications describe the amount of numerical resolution available on the display.
Higher display resolution can be useful when observing small changes, but it should not be confused with uncertainty, stability or calibration accuracy.
Frequency Range and Bandwidth
AC voltmeters are designed to operate over a specified frequency range. The measurement error can increase when the signal frequency approaches or exceeds the meter's specified bandwidth.
For industrial power systems operating near mains frequency, bandwidth requirements can be modest. Electronic test, inverter and high-frequency applications may require substantially broader measurement capability.
Voltmeters for 12 V and Vehicle Electrical Systems
Voltmeters are commonly used to monitor batteries and charging systems in vehicles, mobile machinery, generators and other DC-powered equipment.
Panel voltmeters can provide continuous indication of system voltage, while portable meters are used for diagnostics and maintenance.
The meter's range should comfortably cover the expected system voltage, including charging conditions and abnormal events, and the installation should be suitable for vibration, temperature and electrical transients.
Industrial Panel Voltmeter Applications
Industrial panel voltmeters provide continuous local monitoring in equipment such as:
- electrical switchboards
- control cabinets
- generators
- UPS systems
- battery systems
- industrial power supplies
- machine tools
- automation equipment
- test benches
A panel meter may provide only a local display or may also include relays, analog outputs or digital communications for integration with a control system.
High-Voltage Voltmeters
High-voltage measurement requires instruments and accessories specifically designed for the voltage level and energy available in the circuit.
Depending on the application, the measurement system may use high-voltage dividers, electrostatic measurement methods, specialized probes or isolated instrumentation.
Do not extend a standard voltmeter beyond its rated range by improvising external components. High-voltage measurement systems should be selected and installed according to the instrument manufacturer's ratings and applicable electrical-safety requirements.
Voltage Rating and Measurement Category
For measurements on energized mains and distribution systems, voltage range alone is not sufficient to determine whether an instrument is suitable.
Professional electrical meters can also carry measurement-category ratings that reflect the transient-energy environment in which they are designed to operate. The meter, probes and accessories should all be appropriate for the intended circuit.
Hand-held meters capable of measuring mains voltage are covered by applicable requirements in the IEC 61010 family of electrical measurement safety standards. Always verify the specific standard, category and voltage rating claimed by the manufacturer for the instrument being considered.
Voltmeter Calibration
Voltmeter calibration compares the instrument's readings with known reference voltages generated or measured by traceable reference equipment.
Calibration can evaluate one or more ranges and may include both DC and AC functions when applicable.
The required calibration interval depends on measurement risk, accuracy requirements, quality-system procedures, usage, environmental conditions and instrument history.
How to Choose a Voltmeter
1. Define AC, DC or Both
Start by determining whether the application requires DC measurement, AC measurement or both. For AC, define the waveform and frequency range.
2. Define the Voltage Range
Select a measurement range that covers the normal operating voltage and expected maximum conditions without unnecessarily sacrificing resolution.
3. Check Input Impedance
High input impedance is important when the measured circuit could be affected by meter loading.
4. Define Accuracy and Resolution
Choose measurement performance according to the engineering decision that will be made from the result. Precision laboratory work may require different specifications from a local panel indication.
5. Check AC Frequency Range
For AC measurement, confirm that the instrument's frequency response covers the signal being measured.
6. Determine Whether True RMS Is Required
If non-sinusoidal AC waveforms are expected, consider a true-RMS instrument suitable for the required bandwidth and crest-factor conditions.
7. Choose Display Type and Installation
Determine whether the application needs a handheld meter, bench instrument, analog panel meter or digital panel meter.
8. Check Safety Ratings
For live electrical systems, verify the instrument's voltage rating, measurement category, insulation design and compatible probes.
9. Consider Environmental Conditions
Temperature, humidity, vibration, dust, washdown and outdoor exposure can affect the required enclosure and meter construction.
10. Determine Data and Output Requirements
Industrial installations may require relay outputs, analog retransmission, serial communication, Ethernet or other interfaces in addition to the local voltage display.
11. Consider Calibration and Traceability
Laboratory, production and quality-controlled applications may require periodic calibration and documented traceability.
Explore voltmeters from industrial manufacturers and suppliers on FactoryMore: Voltmeters.
Why Do Voltmeter Prices Vary?
Voltmeter cost depends on the measurement range, accuracy, resolution, input impedance, AC bandwidth, safety rating, display technology, enclosure, calibration documentation and communication features.
A simple panel indicator and a high-accuracy laboratory voltmeter are designed for very different tasks, so price should be compared only after the required measurement performance and installation conditions are defined.
Common Voltmeter Measurement Mistakes
- Connecting the meter in series: Voltmeters are normally connected in parallel across the measured points.
- Using the wrong AC/DC setting: The selected measurement function must match the signal.
- Exceeding the voltage rating: Never measure beyond the meter or probe limits.
- Ignoring measurement category: A meter suitable for low-energy electronics may not be suitable for a high-energy distribution system.
- Using insufficient input impedance: The meter can load high-resistance circuits and change the voltage being measured.
- Confusing resolution with accuracy: More digits do not automatically produce a more accurate measurement.
- Ignoring frequency limits: AC measurement performance can change with frequency and waveform shape.
- Reading the wrong analog scale: Analog meters can have several scales corresponding to different ranges.
Voltmeter Selection Checklist
Before choosing or requesting a quotation for a voltmeter, define:
- AC, DC or combined measurement
- minimum and maximum voltage
- required accuracy
- required resolution
- input resistance or impedance
- AC frequency range
- true-RMS requirement
- handheld, bench or panel installation
- analog or digital display preference
- measurement category and safety rating
- environmental conditions
- communication or relay-output requirements
- calibration and documentation requirements
Frequently Asked Questions
What are voltmeters used for?
Voltmeters are used to measure electrical potential difference between two points. They are used in electronics, electrical systems, industrial machinery, panels, power supplies, batteries and maintenance work.
How is a voltmeter used in an electric circuit?
A voltmeter is normally connected in parallel across the two points whose voltage is to be measured. The meter should be configured for the correct AC or DC function and must be appropriately rated for the circuit.
What are the two types of voltmeters?
A common broad classification is analog and digital voltmeters. However, voltmeters can also be classified as electrostatic, panel, portable, AC, DC and other specialized types according to their measurement principle and application.
Which voltmeter is best?
The best voltmeter depends on the application. Consider voltage range, AC or DC measurement, accuracy, input impedance, bandwidth, safety rating, installation style and whether data outputs are required.
What is the difference between a voltmeter and a multimeter?
A voltmeter is primarily designed to measure voltage. A multimeter combines voltage measurement with additional functions such as current and resistance measurement.
Is a voltmeter AC or DC?
Voltmeters can be designed for AC, DC or both. The instrument must be configured for the correct signal type before measurement.
Why do voltmeters have high resistance?
High resistance minimizes current drawn by the voltmeter and reduces the effect of the measurement on the circuit voltage.
Why are voltmeters connected in parallel?
Voltage is the potential difference between two points, so the meter is connected across those points in parallel to measure that difference directly.
How do I read a voltmeter?
A digital meter displays the voltage numerically. With an analog voltmeter, identify the selected range and read the pointer position on the corresponding scale.
How much do voltmeters cost?
Pricing varies widely because voltmeters range from simple panel indicators to precision laboratory and high-voltage instruments. Compare products based on required measurement range, accuracy, safety, input impedance and features rather than price alone.
